Availability : 2 - 3 weeks
Chest Type Medical Freezers -25? CMF-108 is a horizontal box-shaped freezer with a lid on the top. Compatible with CFC-free polyurethane foam technology and insulating door for better effect of thermal insulation.
Available with maximum capacities about 508 L. Suitable for laboratory and medical application and best for storage of special materials, blood plasma, and vaccine and biological products. Provide battery-based alarm system for audible and visual alarm signal during electrical failure or short circuit. The alarm has an over and under temperature setting, alarm silencing switch, and battery test switch. The construction chamber is PCM internal and cold rolled steel plate with spraying external finish.
| refrigerant | R290a |
|---|---|
| defrosting | - |
| model_type | Chest |
| power | 300 W |
| temperature_range | -10 to -25�C |
| capacity | 508 L |
| model | CMF-108 |
|
Model |
CMF-126 |
CMF-158 |
CMF-108 |
|||
|
Capacity |
226 L |
358 L |
508 L |
|||
|
Temperature Range |
-10 to -25°C |
|||||
|
Materials |
Internal: PCM, External: Cold rolled steel plate with spraying |
|||||
|
Alarms |
Visual & Audio;High/low temperature alarm, senor error alarm, |
|||||
|
Cooling |
Direct cooling |
|||||
|
Class |
N |
|||||
|
Type |
Chest |
|||||
|
Display |
Digital display |
|||||
|
Refrigerant |
R290a |
|||||
|
Evaporator |
D-form copper tube |
|||||
|
Casters |
4 |
|||||
|
Compressor |
1 pc |
|||||
|
Motor |
Fan Motor: EBM |
|||||
|
Interface |
Standard USB |
|||||
|
Accuracy |
0.1? |
|||||
|
Ambient Temperature |
16 to 32°C |
|||||
|
Power Consumption |
150 W |
121 W |
300 W |
|||
|
Internal Dimension |
954×410×703 mm |
1200×545×673 mm |
1504×545×673 mm |
|||
|
External Dimension |
1115×610×890 mm |
1350×735×880 mm |
1650×735×880 mm |
|||
|
Net Weight |
65 kg |
70 kg |
70 kg |
|||
|
Electrical Requirement |
220V/50Hz |
110V/60Hz |
220V/50Hz |
110V/60Hz |
220V/50Hz |
110V/60Hz |
|
Catalogue No. |
500250502 |
500250501 |
500251002 |
500251001 |
500251502 |
500251501 |
