Availability : 2 - 3 weeks
Horizontal Laminar Flow Cabinet LHB-240 used in medicine, pharmacy, and biological, chemical experiment, operating room, foodstuff, drinks, and cosmetic, stock rising and aviation works.
The horizontal intense clean bench is a general-purpose workbench, with clean air flow flows from the top to the bottom in the vertical direction.
Accommodates maximum no. of colony rate: ≤0.5per utensil hour (90mm utensil) and air velocity 0.25-0.45m/s. features with HEPA Filter, UV lamp, sliding glass door, ventilating slot, color plate, and LED source.
| Cleanliness | Grade 100 |
|---|---|
| working_area | 700x650x620mm |
| velocity | 0.25-0.45m/s |
| noise | ?62dB |
| model_type | Single-Horizontal |
| power | 400 W |
| model | LHB-240 |
|
Model |
LHB-210 |
LHB-220 |
LHB-230 |
LHB-240 |
|
Type |
Double-Single-Horizontal |
Double-Single-Horizontal |
Double-Single-Horizontal |
Single-Horizontal |
|
Cleanliness |
Grade 100 |
|||
|
Velocity |
0.25-0.45m/s |
|||
|
Material |
304 Stainless steel |
|||
|
No. of colony |
≤0.5per utensil.hour(90mm utensil) |
|||
|
Noise |
≤62dB |
|||
|
Illumination |
≥300LX |
|||
|
Light |
LED |
|||
|
HEPA filter No. and Size |
1135x600x38 mmx1 |
695X500X38X 1 |
30W*1/30W*1 |
695x600x38 mm x1 |
|
Power Consumption |
300 W |
800 W |
800 W |
400 W |
|
Certification |
ISO 9001
|
|||
|
Working Area |
1150x400x600 mm |
1140x550x415 mm |
1360x550x620 mm |
700x650x620mm |
|
Overall Dimension |
1300x580x1600 mm |
1300X550X1600 mm |
1540x730x1600 mm |
880x770x1800 mm |
|
Weight |
150 kg |
320 kg |
320 kg |
150 kg |
|
Electrical Requirement |
AC, 220 V/50Hz |
|||
|
Catalogue No. |
380400502 |
380401002 |
380401502 |
380402002 |
