Availability : 2 - 3 weeks
Horizontal Laminar Flow Cabinet LHB-140 available with double Horizontal cabinet configurations, used in medicine, pharmacy, and biological, chemical experiment, operating room, foodstuff, drinks, and cosmetic, stock rising and aviation works.
The horizontal intense clean bench is a general-purpose workbench, with clean air flow flows from the top to the bottom in the vertical direction. Accommodates maximum no. of colony rate: ≤0.5per utensil hour (90mm utensil) and air velocity 0.25-0.45m/s.
Features with HEPA Filter, UV lamp, sliding glass door, ventilating slot, color plate, and LED source. Deliver best and economic free environment for inflexible contamination requirements on pharmaceutical, food industries, biotech and much more Industries. Our flow cabinet enclosed on the sides and kept under constant pressure to prevent contamination.
| Cleanliness | Grade 100 |
|---|---|
| working_area | 1030X650X620 mm |
| velocity | 0.25-0.45m/s |
| noise | ?62dB |
| model_type | Double Horizontal |
| power | 800 W |
| model | LHB-140 |
|
Model |
LHB-110 |
LHB-120 |
LHB-130 |
LHB-140 |
|
Type |
Single-Single-Horizontal |
Single-Single-Horizontal |
Single-Single-Horizontal |
Double Horizontal |
|
Cleanliness |
Grade 100 |
|||
|
Velocity |
0.25-0.45m/s |
|||
|
Material |
304 Stainless steel |
|||
|
No. of colony |
≤0.5per utensil.hour(90mm utensil) |
≤0.5per utensil.hour(90mm utensil) |
≤0.5per utensil.hour(90mm utensil) |
≤0.5per utensil.hour(90mm utensil) |
|
Noise |
≤62dB |
|||
|
Illumination |
≥300LX |
|||
|
Light |
LED |
|||
|
HEPA filter No. and Size |
695x600x38 mm x1 |
20W*1/20W*1 |
20W*1/20W*1 |
1135x600x38 mm x1 |
|
Power Consumption |
300 W |
320 W |
320 W |
800 W |
|
Certification |
ISO 9001
|
ISO 9001 |
ISO 9001 |
ISO 9001 |
|
Working Area |
700x400x600 mm |
850×580×1600 mm |
870x550x620 mm |
1030X650X620 mm |
|
Overall Dimension |
850x580x1600 mm |
850×580×1600 mm |
1050x730x1600 mm |
1300X770X1800 mm |
|
Weight |
160 kg |
250 kg |
||
|
Electrical Requirement |
AC, 220 V/50Hz |
|||
|
Catalogue No. |
380350502 |
380351002 |
380351502 |
380352002 |
